High frequency, 230VAC output
Product Origin:
ChinaColor:
Nature, or can be customizedShipping Port:
XiamenBrand:
WintopModel:
SPF 5000ES5000ES Solar Off-Grid Energy Storage Inverter Supplier
Product Description
This SPF 5000 ES inverter is an off-grid PV inverter with a 230VAC output voltage for backup power and self-consumption applications with a maximum PV input voltage of up to 450VDC. It can also work without batteries, saving system investment costs.
This is a multifunctional off-grid solar inverter that integrates MPPT solar charge controller, high frequency pure sine wave inverter and UPS function module, ideal for off-grid backup power and self-consumption applications. This inverter can work with or without batteries.
Technical Parameters
|
BATTERY |
Battery Voltage
|
48VDC
|
|
Battery Type
|
Lithium/Lead-acid
|
|
|
INVERTER OUTPUT
|
Rated Power
|
5000VA/ 5000W
|
|
Parallel Capability |
Yes, 6 units maximum
|
|
|
AC Voltage Regulation (Battery Mode) |
230VAC ± 5% @ 50/60Hz
|
|
|
Surge Power |
10000VA
|
|
|
Efficiency (Peak) |
93%
|
|
|
Waveform
|
Pure sine wave
|
|
|
Transfer Time
|
10ms typical, 20ms Max
|
|
|
SOLAR CHARGER
|
Maximum PV Array Power |
6000W
|
| MPPT Range @ Operating Voltage |
120VDC ~ 430VDC
|
|
|
Number of Independent MPP Trackers/Strings Per MPP Tracker
|
1/1
|
|
| Maximum PV Array Open Circuit Voltage |
450VDC
|
|
|
Maximum Solar Charge Current
|
100A
|
|
|
AC CHARGER
|
Charge Current |
80A
|
|
AC Input Voltage |
230 VAC
|
|
| Selectable Voltage Range |
170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances)
|
|
|
Frequency Range
|
50Hz/60Hz (Auto sensing)
|
|
|
PHYSICAL
|
Protection Degree
|
IP20
|
|
Dimension (W/H/D)
|
330/485/135mm
|
|
|
Net Weight
|
12kgs
|
|
|
OPERATING ENVIRONMENT
|
Humidity
|
5% to 95% Relative Humidity(Non-condensing)
|
|
Altitude
|
<2000m
|
|
|
Operating Temperature
|
0°C - 55°C
|
|
|
Storage Temperature
|
-15°C - 60°C
|
Installation
Do not mount the inverter on flammable construction materials.Mount on a solid surface.
The recommended installation position is to be adhered to the wall vertically.
Make sure to keep a certain distance from other objects and surfaces to ensure adequate heat dissipation and enough room to remove wires.
Product Overview
| Number |
Product Name |
| 1 |
LCD display
|
| 2 |
Status indicator
|
| 3 |
Charging indicator
|
| 4 |
Fault indicator
|
| 5 |
Function buttons
|
| 6 |
AC input
|
| 7 |
WiFi/GPRS communication port
|
| 8 |
USB communication port
|
| 9 |
BMS communication port (support CAN/RS485 protocol)
|
| 10 |
RS485 communication port (for expansion)
|
| 11 |
Dry contact
|
| 12 |
PV input
|
| 13 |
Power on/off switch
|
| 14 |
Battery input
|
| 15 |
Parallel communication ports
|
| 16 |
Current sharing ports
|
| 17 |
AC output
|
| 18 |
Circuit breaker
|
